60 • Xtium2-CLHS PX8 Reference Xtium2-CLHS PX8 User's Manual
CORACQ_PRM_MASTER_MODE Not available
CORACQ_PRM_SHAFT_ENCODER_DROP min = 0 tick
max = 254 tick
step = 1 tick
CORACQ_PRM_SHAFT_ENCODER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_TRIGGER_FRAME_COUNT
min = 1 frame
max = 262142 frame
step = 1 frame
Note: Infinite not supported
CORACQ_PRM_INT_FRAME_TRIGGER_ENABLE
TRUE
FALSE
CORACQ_PRM_INT_FRAME_TRIGGER_FREQ
min = 1 milli-Hz
max = 1000000000 milli-Hz
step = 1 milli-Hz
CORACQ_PRM_STROBE_DELAY_2 Not Available
CORACQ_PRM_FRAME_LENGTH
CORACQ_VAL_FRAME_LENGTH_FIX (0x1)
CORACQ_VAL_FRAME_LENGTH_VARIABLE (0x2)
CORACQ_PRM_FLIP
CORACQ_VAL_FLIP_OFF (0x00)
CORACQ_VAL_FLIP_HORZ (0x01)
CORACQ_PRM_EXT_TRIGGER_DURATION min = 0 µs
max = 255 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_DELAY min = 0 µs
max = 42949672 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_DELAY min = 0 µs
max = 42949672 µs
step = 1 µs
CORACQ_PRM_SHAFT_ENCODER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_LUT_NENTRIES
8-bit/pixel component
10-bit/pixel component
12-bit/pixel component
14/16-bit/pixel component
256 entries
1024 entries
4096 entries
0 entries
CORACQ_PRM_EXT_FRAME_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE (*) min = 0
max = 5
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE (*)
min = 0
max = 5
step = 1
CORACQ_PRM_SHAFT_ENCODER_MULTIPLY
min = 1
max = 32
step = (2
N
)
CORACQ_PRM_EXT_TRIGGER_DELAY
min = 0
max = 16777215
step = 1
CORACQ_PRM_EXT_TRIGGER_DELAY_TIME_BASE
CORACQ_VAL_TIME_BASE_LINE_VALID (0x4)
CORACQ_VAL_TIME_BASE_LINE_TRIGGER (0x8)
CORACQ_VAL_TIME_BASE_SHAFT_ENCODER (0x40)
CORACQ_VAL_TIME_BASE_NS (0x80)
CORACQ_PRM_COLOR_DECODER_ENABLE Not Available
CORACQ_PRM_WB_GAIN RGB
Min = 100000
max = 900000
step = 1
CORACQ_PRM_WB_GAIN_RED RGB
Min = 100000
max = 900000
step = 1
CORACQ_PRM_WB_GAIN_GREEN RGB
Min = 100000
max = 900000
step = 1
CORACQ_PRM_WB_GAIN_BLUE RGB Min = 100000
max = 900000
step = 1
CORACQ_PRM_EXT_TRIGGER_IGNORE_DELAY min = 0
max = 42949672
step = 1
