Xtium2-CLHS PX8 User's Manual Xtium2-CLHS PX8 Reference • 59
CORACQ_PRM_STROBE_DELAY
min = 0 µs
max = 42949672 µs
step = 1 µs
CORACQ_PRM_TIME_INTEGRATE_ENABLE
TRUE
FALSE
CORACQ_PRM_TIME_INTEGRATE_DURATION min = 1 µs
max = 42949672 µs
step = 1 µs
CORACQ_PRM_CAM_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_OUTPUT_FORMAT
Mono
RGB
CORACQ_VAL_OUTPUT_FORMAT_MONO8
CORACQ_VAL_OUTPUT_FORMAT_MONO16
CORACQ_VAL_OUTPUT_FORMAT_MONO8P2
CORACQ_VAL_OUTPUT_FORMAT_MONO8P3
CORACQ_VAL_OUTPUT_FORMAT_MONO8P4
CORACQ_VAL_OUTPUT_FORMAT_RGB8888
CORACQ_VAL_OUTPUT_FORMAT_RGB888
CORACQ_VAL_OUTPUT_FORMAT_RGBP8
CORACQ_PRM_EXT_TRIGGER_ENABLE
CORACQ_VAL_EXT_TRIGGER_OFF (0x1)
CORACQ_VAL_EXT_TRIGGER_ON (0x8)
CORACQ_PRM_VIC_NAME Mono
RGB
Default Camera Link HS Line Scan Mono
Default Camera Link HS Line Scan Color
CORACQ_PRM_LUT_MAX 1
CORACQ_PRM_EXT_TRIGGER_DETECTION
CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_LUT_FORMAT Default = CORDATA_FORMAT_COLORNI8
CORACQ_PRM_LINE_INTEGRATE_ENABLE TRUE
FALSE
CORACQ_PRM_LINE_INTEGRATE_DURATION
min = 1 nsec
max = 4294967295 nsec
step = 1 nsec
CORACQ_PRM_LINE_TRIGGER_ENABLE
TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_ENABLE TRUE
FALSE
CORACQ_PRM_EXT_FRAME_TRIGGER_DETECTION CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_VAL_DOUBLE_PULSE_RISING_EDGE (0x20)
CORACQ_VAL_DOUBLE_PULSE_FALLING_EDGE (0x40)
CORACQ_VAL_DOUBLE_PULSE_RISING_EDGE_ORDER_REVERSE (0x80)
CORACQ_VAL_DOUBLE_PULSE_FALLING_EDGE_ORDER_REVERSE
(0x100)
CORACQ_PRM_EXT_LINE_TRIGGER_ENABLE
TRUE
FALSE
CORACQ_PRM_EXT_LINE_TRIGGER_DETECTION CORACQ_VAL_RISING_EDGE (0x4)
CORACQ_VAL_FALLING_EDGE (0x8)
CORACQ_PRM_SNAP_COUNT Not Available
CORACQ_PRM_INT_LINE_TRIGGER_ENABLE
TRUE
FALSE
CORACQ_PRM_INT_LINE_TRIGGER_FREQ Default = 5000 Hz
CORACQ_PRM_BIT_ORDERING CORACQ_VAL_BIT_ORDERING_STD (0x1)
CORACQ_PRM_EXT_TRIGGER_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_VAL_LEVEL_12VOLTS (0x040)
CORACQ_VAL_LEVEL_24VOLTS (0x8)
CORACQ_PRM_STROBE_LEVEL CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_PRM_EXT_FRAME_TRIGGER_LEVEL
CORACQ_VAL_LEVEL_TTL (0x1)
CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_VAL_LEVEL_12VOLTS (0x040)
CORACQ_VAL_LEVEL_24VOLTS (0x8)
CORACQ_PRM_EXT_LINE_TRIGGER_LEVEL CORACQ_VAL_LEVEL_422 (0x2)
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MIN 8 Hz
CORACQ_PRM_INT_LINE_TRIGGER_FREQ_MAX 500000 Hz
