74 • Technical Specifications Xtium2-CLHS PX8 User's Manual
CLHS
High Bandwidth
Camera
Xtium-CLHS
#1
J3
J2
Xtium-CLHS
#2
J3
J2
Xtium-CLHS
#6
J3
J2
CLHS Cable
CLHS Cable
CLHS Cable(s)
Data
Forwarding
Master
Data Forwarding
Slave #1
Data Forwarding
Slave #5
Figure 21: Data Forwarding Block Diagram
