Procedure
1. Check that the delivery agrees to the order, see 4.1 Checking the Delivery.
2. Before starting the commissioning, read carefully the safety instructions in 2.2 Danger and Warnings and 2.3 Cautions and Notices.
3. Before the mechanical installation, check the minimum clearances around the AC drive ( 5.2.2 Cooling of FR4 to FR9 and 5.2.3
Cooling of Standalone AC drives (FR10 to FR11)) and check the ambient conditions in 12.8 VACON NXP Technical Data.
4. Check the dimensions of the motor cable, mains cable, mains fuses and check the cable connections. Read 6.1 Cable Connections,
6.2 EMC-compliant Installation and 6.3 Grounding.
5. Obey the installation instructions, see 6.5 Installing the Cables.
6. Find information on the control connections in 7.3.2 Control Terminals on OPTA1.
7. If the start-up wizard is active, select the language of the control panel and the application. Accept the selections with the Enter
button. If the start-up wizard is not active, obey the instructions a and b.
A Select the language of the control panel from the Menu M6, page 6.1. For instructions, see 8.7.3 Changing the Language.
B Select the application from the Menu M6, page 6.2. For instructions, see 8.7.4 Changing the Application.
8. All parameters have factory default values. To make sure that the AC drive operates correctly, make sure that these group G2.1
parameters have the same data as the nameplate. For more information on the parameters in the list, see the VACON
®
All in One
Application Manual.
• Nominal voltage of the motor
• Nominal frequency of the motor
•
Nominal speed of the motor
• Nominal current of the motor
• Motor cos phi
9. Obey the commissioning instructions, see 9.2 Commissioning the AC Drive.
The VACON
®
NXS/NXP AC drive is ready for operation.
Introduction
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G
10 | Danfoss A/S © 2018.06
