Danfoss Vacon NXP Series User Manual

Procedure
1. To find the Keypad control menu, scroll down in the main menu until the location indication M3 shows on the first line of the
display.
READY
STOP
I/O term
P1
P4
e30bg033.10
Keypad control
2. To go to the Keypad control menu from the main menu, push the Menu button Right.
8.4.2 Keypad Control Parameters M3
Table 13: Keypad Control Parameters, M3
Index Parameter Min Max Unit Default Cust ID Description
P3.1 Control place 1 3 1 125 The control mode
1 = I/0 terminal
2 = Keypad (control panel)
3 = Fieldbus
R3.2 Keypad reference P2.1.1 P2.1.2 Hz 0.00 123 0 = Forward
1 = Reverse
P3.3 Direction (on keypad) 0 1 0
P3.4 Stop button 0 1 1 114 0 = Limited function of Stop button
1 = Stop button always enabled
8.4.3 Changing the Control Mode
Context:
3 control modes are available to control the AC drive. For each control place, a different symbol shows on the display:
The control mode The symbol
I/O terminals
I/O term
Keypad (control panel)
Keypad
Fieldbus
Bus/Comm
Using the Control Panel
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G | 91
Danfoss A/S © 2018.06
