Danfoss Vacon NXP Series - Accessing Terminals and Installing Cables; Get Access and Locate the Terminals for FR4

WARN I N G
SHOCK HAZARD FROM PE CONDUCTOR
The drive can cause a DC current in the PE conductor. Failure to use a residual current-operated protective (RCD) device Type B
or a residual current-operated monitoring (RCM) device can lead to the RCD not providing the intended protection and
therefore can result in death or serious injury.
-
Use a type B RCD or RCM device on the mains side of the drive.
6.4 Get Access and Locate the Terminals
6.4.1 Get Access and Locate the Terminals for FR4
Context:
Follow these instructions to open the AC drive for installing the cables, for example.
Electrical Installation
