FR7
A
D
B
C
e30bg092.10
A Control terminals
C Motor terminals
B Brake resistor terminals
D Grounding terminals
Illustration 18: FR7 Terminals
6.4.5 Get Access and Locate the Terminals for FR8
Context:
Follow these instructions to open the AC drive for installing the cables, for example.
Electrical Installation
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G
52 | Danfoss A/S © 2018.06
