12.7.6 Power Ratings for Mains Voltage 525–690 V (UL Rating 600 V)
Table 49: Power Ratings in Mains 525–600 V, 50 Hz, 3~
Enclosure
size
Drive
type
Input
current
I
in
(1)
Low
loadabili-
ty: I
L
[A]
(2)
Low
loadabili-
ty: 10%
overload
I [A]
High
loadabili-
ty: I
H
[A]
(2)
High
loadabili-
ty: 50%
overload
I [A]
Loadabili-
ty: Max I
S
2 s
Motor
shaft
power
(3)
:
10% over-
load 40°C
[kW]
Motor
shaft
power
(3)
:
50% over-
load 50°C
[kW]
FR6 0004 4.5 4.5 5.0 3.2 4.8 6.4 3.0 2.2
0005 5.5 5.5 6.1 4.5 6.8 9.0 4.0 3.0
0007 7.5 7.5 8.3 5.5 8.3 11.0 5.5 4.0
0010 10.0 10.0 11.0 7.5 11.3 15.0 7.5 5.5
0013 13.5 13.5 14.9 10.0 15.0 20.0 11.0 7.5
0018 18.0 18 19.8 13.5 20.3 27.0 15.0 11.0
0022 22.0 22.0 24.2 18.0 27.0 36.0 18.5 15.0
0027 27.0 27.0 29.7 22.0 33.0 44.0 22.0 18.5
0034 34.0 34.0 37.0 27.0 41.0 54.0 30.0 22.0
FR7 0041 41.0 41.0 45.0 34.0 51.0 68.0 37.5 30.0
0052 52.0 52.0 57.0 41.0 62.0 82.0 45.0 37.5
FR8 0062 62.0 62.0 68.0 52.0 78.0 104.0 55.0 45.0
0080 80.0 80.0 88.0 62.0 93.0 124.0 75.0 55.0
0100 100.0 100.0 110.0 80.0 120.0 160.0 90.0 75.0
FR9 0125 125.0 125.0 138.0 100.0 150.0 200.0 110.0 90.0
0144 144.0 144.0 158.0 125.0 188.0 250.0 132.0 110.0
0170 170.0 170.0 187.0 144.0 216.0 288.0 160.0 132.0
0208 208.0 208.0 229.0 170.0 255.0 340.0 200.0 160.0
FR10
(3)
0261 261.0 261.0 287.0 208.0 312.0 416.0 250.0 200.0
0325 325.0 325.0 358.0 261.0 392.0 522.0 315.0 250.0
0385 385.0 385.0 424.0 325.0 488.0 650.0 355.0 315.0
0416 416.0 416.0 358.0 325.0 488.0 650.0 400.0 315.0
FR11
(3)
0460 460.0 460.0 506.0 385.0 578.0 770.0 450.0 355.0
0502 502.0 502.0 552.0 460.0 690.0 920.0 500.0 450.0
0590 590.0 590.0 649.0 502.0 753.0 1004.0 560.0 500.0
1
The currents in given ambient temperatures are achieved only when the switching frequency is the same or smaller than the factory default.
2
See 12.7.1 Overload Capability
3
690 V
Specifications
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G
152 | Danfoss A/S © 2018.06
