Danfoss Vacon NXP Series User Manual

Enclo-
sure size
Drive type Fuse Class
Fast Act-
ing (T/J)
[A]
Mains, Motor, and brake re-
sistor cable Cu [AWG]
(1) (2)
Mains terminal [AWG] Grounding terminal
[AWG]
FR5 0017 2
0016 5
20 3*12 AWG + 12 AWG 18 AWG - 8 AWG 18 AWG - 8 AWG
0025 2
0022 5
30 3*10 AWG + 10 AWG 18 AWG - 8 AWG 18 AWG - 8 AWG
0031 2
0031 5
40 3*8 AWG + 8 AWG 18 AWG - 8 AWG 18 AWG - 8 AWG
FR6 0038 5 50 3*8 AWG + 8 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 2 AWG
0048 2
0045 5
60 3*8 AWG + 8 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 2 AWG
0061 2
0061 5
90 3*6 AWG + 6 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 2 AWG
FR7 0075 2
0072 5
90 3*4 AWG + 6 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
10 AWG - 2/0 AWG
0088 2
0087 5
110 3*2 AWG + 6 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
10 AWG - 2/0 AWG
0114 2
0105 5
150 3*2 AWG + 4 AWG 14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
10 AWG - 2/0 AWG
FR8 0140 2
0140 5
175 3*2/0 AWG + 2 AWG 4 AWG - 3/0 AWG Cu/Al 10 AWG - 3/0 AWG
0170 2
0168 5
250 3*3/0 AWG + 1/0 AWG 3/0 AWG - 350 kcmil Cu/Al 10 AWG - 3/0 AWG
0205 2
0205 5
250 3*300 kcmil + 2/0 AWG 3/0 AWG - 350 kcmil Cu/Al 10 AWG - 3/0 AWG
FR9 0261 2
0261 5
350 3*350 kcmil + 3/0 AWG
2*(3*250 kcmil + 2/0 AWG)
3/0 AWG - 350 kcmil Cu/Al 10 AWG - 3/0 AWG
0300 2
0300 5
400 2*(3*250 kcmil + 2/0 AWG) 3/0 AWG - 350 kcmil Cu/Al 10 AWG - 3/0 AWG
1
Uses a correction factor 0.7
Specifications
Operating guide | VACON® NXS/NXP Air-cooled
DPD00910G | 139
Danfoss A/S © 2018.06

Danfoss Vacon NXP Series Specifications

General

Product Series	Vacon NXP
Category	Controller
Output Frequency Range	0-500 Hz
Control Modes	Speed control, torque control, position control
Cooling Method	Air-cooled, liquid-cooled
Input Voltage Range	±10%
Output Voltage Range	0-480 V
Enclosure	IP21, IP54
Control Method	V/f control, Vector control
Braking Chopper	Built-in or external
Communication Interfaces	Ethernet, CANopen, Profibus, Modbus
Protection Features	Overcurrent, overvoltage, overtemperature
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
