Code Description
SSS The hardware changes:
• The supply, the first letter (
Xxx):
- S = 6-pulse connection (FR4 to FR11)
- B = Additional DC-connection (FR8 to FR11)
- J = FR10 to 11 stand-alone with main switch and DC-link terminals
• The mounting, the second letter: (xXx):
- S = Air-cooled drive
• The boards, the third letter (xxX):
- S = Standard boards (FR4 to FR8)
- V = Coated boards (FR4 to FR8)
- F = Standard boards (FR9 to FR11)
- G = Coated boards (FR9 to FR11)
- A = Standard boards (FR10 to FR11 standalone drives)
- B = Coated boards (FR10 to FR11 standalone drives)
- N = separate IP54 (UL Type 12) control box, standard boards (FR9 IP00, ≥ FR10)
- O = separate IP54 (UL Type 12) control box, coated boards (FR9 IP00, ≥ FR10)
- X = separate IP00 control box, standard boards (FR9 IP00)
- Y = separate IP00 control box, coated boards (FR9 IP00)
A1A2C30000 The option boards. 2 characters for each slot. 00 = the slot is not used
The option board abbreviations:
•
A = basic I/O board
•
B = expander I/O board
• C = fieldbus board
• D = special board
• E = fieldbus board
For example, C3 = PROFIBUS DP
+DNOT The optional codes. There are many options.
The options that are related to ordering of paper manuals are:
•
+DNOT = No paper manuals, only Quick Guide and Safety Guide
•
+DPAP = With English paper manuals
• +DPAP+DLDE = With German paper manuals
1
A brake resistor is available as an option for external installation for 208–240 V (FR7-FR11), 380–500 V (FR7-FR11), and 525–690 V (all enclosure sizes).
