Danfoss VLT AQUA Drive FC 202 Design Manual

202 (8.0)
130BF372.10
0.0
1
2
3
1
3
2
M10
20 (0.8)
15 (0.6)
40 (1.6)
M10
15 (0.6)
16 (0.6)
32 (1.3)
M10
20
14 (0.5)
18 (0.7)
(0.8)
35 (1.4)
1 Mains terminals 3 Motor terminals
2 Brake terminals – –
Figure 8.69 D8h Terminal Dimensions with Circuit Breaker Option (Side View)
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
122 Danfoss A/S © 01/2018 All rights reserved. MG22B222
