VLT
®
AQUA Drive FC 202
N200 N250
High/normal overload HO NO HO NO
(High overload=150% current during 60 s, normal overload=110%
current during 60 s)
Typical Shaft output at 525 V [kW] 132 160 160 200
Typical Shaft output at 575 V [hp] 200 250 250 300
Typical Shaft output at 690 V [kW] 160 200 200 250
Enclosure size D2h/D4h/D7h/D8h
Output current (3-phase)
Continuous (at 525 V) [A] 201 253 253 303
Intermittent (60 s overload) (at 525 V) [A] 301 278 380 333
Continuous (at 575/690 V) [A] 192 242 242 290
Intermittent (60 s overload) (at 575/690 V) [A] 288 266 363 319
Continuous kVA (at 525 V) [kVA] 183 230 230 276
Continuous kVA (at 575 V) [kVA] 191 241 241 289
Continuous kVA (at 690 V) [kVA] 229 289 289 347
Maximum input current
Continuous (at 525 V) [A] 193 244 244 292
Continuous (at 575/690 V) 185 233 233 279
Maximum number and size of cables per phase
- Mains, motor, brake, and load share [mm
2
(AWG)]
2x185 (2x350) 2x185 (2x350)
Maximum external mains fuses [A]
1)
550 550
Estimated power loss at 575 V [W]
2), 3)
2361 3074 3012 3723
Estimated power loss at 690 V [W]
2), 3)
2446 3175 3123 3851
Eciency
3)
0.98 0.98
Output frequency [Hz] 0–590 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176)
Table 7.7 Electrical Data for Enclosures D2h/D4h/D7h/D8h, Mains Supply 3x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 47
7 7
