VLT
®
AQUA Drive FC 202
N315 N400
High/normal overload HO NO HO NO
(High overload=150% current during 60 s, normal overload=110%
current during 60 s)
Typical Shaft output at 525 V [kW] 200 250 250 315
Typical Shaft output at 575 V [hp] 300 350 350 400
Typical Shaft output at 690 V [kW] 250 315 315 400
Enclosure size D2h/D4h/D7h/D8h
Output current (3-phase)
Continuous (at 525 V) [A] 303 360 360 418
Intermittent (60 s overload) (at 525 V) [A] 455 396 540 460
Continuous (at 575/690 V) [A] 290 344 344 400
Intermittent (60 s overload) (at 575/690 V) [A] 435 378 516 440
Continuous kVA (at 525 V) [kVA] 276 327 327 380
Continuous kVA (at 575 V) [kVA] 289 343 343 398
Continuous kVA (at 690 V) [kVA] 347 411 411 478
Maximum input current
Continuous (at 525 V) [A] 292 347 347 403
Continuous (at 575/690 V) 279 332 332 385
Maximum number and size of cables per phase
- Mains, motor, brake, and load share [mm
2
(AWG)]
2x185 (2x350) 2x185 (2x350)
Maximum external mains fuses [A]
1)
550 550
Estimated power loss at 575 V [W]
2), 3)
3642 4465 4146 5028
Estimated power loss at 690 V [W]
2), 3)
3771 4614 4258 5155
Eciency
3)
0.98 0.98
Output frequency [Hz] 0–590 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176)
Table 7.8 Electrical Data for Enclosures D2h/D4h/D7h/D8h, Mains Supply 3x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications
VLT
®
AQUA Drive FC 202
48 Danfoss A/S © 01/2018 All rights reserved. MG22B222
