Danfoss VLT AutomationDrive FC 301 Design Guide

Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt [kV/μs]
36 240 0.264 0.624 1.890
136 240 0.536 0.596 0.889
150 240 0.568 0.568 0.800
Table 6.14 P7K5T2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
30 240 0.556 0.650 0.935
100 240 0.592 0.594 0.802
150 240 0.708 0.587 0.663
Table 6.15 P11KT2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 240 0.244 0.608 1.993
136 240 0.568 0.580 0.816
150 240 0.720 0.574 0.637
Table 6.16 P15KT2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 240 0.244 0.608 1.993
136 240 0.568 0.580 0.816
150 240 0.720 0.574 0.637
Table 6.17 P18KT2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
15 240 0.194 0.626 2.581
50 240 0.252 0.574 1.822
150 240 0.488 0.538 0.882
Table 6.18 P22KT2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
30 240 0.300 0.598 1.594
100 240 0.536 0.566 0.844
150 240 0.776 0.546 0.562
Table 6.19 P30KT2
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
30 240 0.300 0.598 1.594
100 240 0.536 0.566 0.844
150 240 0.776 0.546 0.562
Table 6.20 P37KT2
380-500 V (T4)
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.640 0.690 0.862
50 480 0.470 0.985 0.985
150 480 0.760 1.045 0.947
Table 6.21 P1K5T4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.172 0.890 4.156
50 480 0.310 2.564
150 480 0.370 1.190 1.770
Table 6.22 P4K0T4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.04755 0.739 8.035
50 480 0.207 4.548
150 480 0.6742 1.030 2.828
Table 6.23 P7K5T4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
Table 6.24 P11KT4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
Table 6.25 P15KT4
Product Specifications
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 79
6 6
