Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 480 0.312 2.846
100 480 0.556 1.250 1.798
150 480 0.608 1.230 1.618
Table 6.26 P18KT4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
15 480 0.288 3.083
100 480 0.492 1.230 2.000
150 480 0.468 1.190 2.034
Table 6.27 P22KT4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.368 1.270 2.853
50 480 0.536 1.260 1.978
100 480 0.680 1.240 1.426
150 480 0.712 1.200 1.334
Table 6.28 P30KT4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.368 1.270 2.853
50 480 0.536 1.260 1.978
100 480 0.680 1.240 1.426
150 480 0.712 1.200 1.334
Table 6.29 P37KT4
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
15 480 0.256 1.230 3.847
50 480 0.328 1.200 2.957
100 480 0.456 1.200 2.127
150 480 0.960 1.150 1.052
Table 6.30 P45KT4
380-500 V (T5)
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.371 1.170 2.523
Table 6.31 P55KT5
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
5 480 0.371 1.170 2.523
Table 6.32 P75KT5
600 V (T6)
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 600 0.304 1.560 4.105
50 600 0.300 1.550 4.133
100 600 0.536 1.640 2.448
150 600 0.576 1.640 2.278
Table 6.33 P15KT6
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
36 600 0.084 1.560 7.962
50 600 0.120 1.540 5.467
100 600 0.165 1.472 3.976
150 600 0.190 1.530 3.432
Table 6.34 P30KT6
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
15 600 0.276 1.184 4.290
Table 6.35 P75KT6
525-690 V (T7)
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
80 690 0.58 1.728 2369
130 690 0.93 1.824 1569
180 690 0.925 1.818 1570
Table 6.36 P7K5T7
Cable
length [m]
Mains
voltage
[V]
Rise time
[μs]
Upeak
[kV]
dU/dt
[kV/μs]
6 690 0.238 1416 4739
50 690 0.358 1764 3922
150 690 0.465 1872 3252
Table 6.37 P45KT7
Product Specifications
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
80 MG33BF02 - Rev. 2013-12-20
66
