Danfoss VLT AutomationDrive FC 301 Design Guide

FC 302 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br.cont.
[kW]
Danfoss part number
Cable
cross
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br.nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T6 0.75 620 914.2 850 0.280 175u3317 175u3104 175u3105 - 1.5 0.6
T6 1.1 550 611.3 570 0.450 175u3318 175u3430 175u3429 - 1.5 0.9
T6 1.5 380 441.9 415 0.570 175u3319 175u3432 175u3431 - 1.5 1.1
T6 2.2 260 296.4 270 0.960 175u3320 175u3434 175u3433 - 1.5 1.8
T6 3 189 214.8 200 1.130 175u3321 175u3436 175u3435 - 1.5 2.3
T6 4 135 159.2 145 1.700 175u3322 175u3126 175u3127 - 1.5 3.3
T6 5.5 99.0 114.5 100 2.200 175u3323 175u3438 175u3437 - 1.5 4.4
T6 7.5 69.0 83.2 72 3.200 175u3324 175u3440 175u3439 - 1.5 6.3
T6 11 48.6 56.1 52 5.500 - 175u3148 175u3149 - 1.5 9.7
T6 15 35.1 40.8 38 6.000 - - - 175u3239 2.5 12.6
T6 18.5 27.0 32.9 31 8.000 - - - 175u3240 4 16
T6 22 22.5 27.6 27 10.000 - - - 175u3200 4 19
T6 30 17.1 21.4 19 14.000 - - - 175u3204 10 27
T6 37 13.5 17.3 14 17.000 - - - 175u3207 10 35
T6 45 10.8 14.2 13.5 21.000 - - - 175u3208 16 40
T6 55 8.8 11.6 11 26.000 - - - 175u3211 25 49
T6 75 6.6 8.4 7.0 30.000 - - - 175u3241 35 66
Table 7.15 T6, Vertical Braking 40% Duty Cycle
How to Order
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 97
7 7
