Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[0]
No operation
All digital and relay outputs are by default set to No Operation.
[1]
Control ready
The control card is ready.
[2]
Drive ready
The drive is ready to operate. Mains and control supplies are OK.
[3]
Drive rdy/rem ctrl
The drive is ready for operation and is in auto-on mode.
[4]
Enable/no warning
Ready for operation. No start or stop commands have been applied (start/disable). No warn-
ings are active.
[5]
Running
The motor is running, and shaft torque is present.
[6]
Running/no warning
Output speed is higher than the speed set in parameter 1-81 Min Speed for Function at Stop
[RPM]. The motor runs and there are no warnings.
[7]
Run in range/no warn
The motor runs within the programmed current and the speed ranges set in parameter 4-50
Warning Current Low and parameter 4-53 Warning Speed High. No warnings.
[8]
Run on ref/no warn
The motor runs at reference speed. No warnings.
[9]
Alarm
An alarm activates the output. No warnings.
[10]
Alarm or warning
An alarm or a warning activates the output.
[11]
At torque limit
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
[12]
Out of current range
The motor current is outside the range set in parameter 4-18 Current Limit.
[13]
Below current, low
The motor current is lower than set in parameter 4-50 Warning Current Low.
[14]
Above current, high
The motor current is higher than set in parameter 4-51 Warning Current High.
[15]
Out of speed range
Output speed/frequency is outside the frequency range set in parameter 4-52 Warning Speed
Low and parameter 4-53 Warning Speed High.
[16]
Below speed, low
Output speed is lower than the setting in parameter 4-52 Warning Speed Low.
[17]
Above speed, high
Output speed is higher than the setting in parameter 4-53 Warning Speed High.
[18]
Out of feedb. range
Feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
[19]
Below feedback, low
Feedback is below the limit set in parameter 4-56 Warning Feedback Low.
[20]
Above feedback, high
Feedback is above the limit set in parameter 4-57 Warning Feedback High.
[21]
Thermal warning
Thermal warning turns on when the temperature exceeds the limit either in motor, drive,
brake resistor, or connected thermistor.
[22]
Ready,no thermal W
The drive is ready for operation and there is no overtemperature warning.
[23]
Remote,ready, no TW
The drive is ready for operation and is in auto-on mode. There is no overtemperature warn-
ing.
[24]
Ready, Voltage OK
The drive is ready for operation and the mains voltage is within the specified voltage range.
[25]
Reverse
The motor runs (or is ready to run) clockwise when logic = 0 and counterclockwise when log-
ic = 1. The output changes as soon as the reversing signal is applied.
[26]
Bus OK
Active communication (no timeout) via the serial communication port.
AU275636650261en-000101 / 130R0334210 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
