Parameter 5-31 Terminal 29 Digital Output
Table 357: Parameter 5-31 Terminal 29 Digital Output
5-31 Terminal 29 Digital Output
Default value: Size related
Change during operation: True
The options for this parameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
Parameter 5-32 Term X30/6 Digi Out (MCB 101)
Table 358: Parameter 5-32 Term X30/6 Digi Out (MCB 101)
5-32 Term X30/6 Digi Out (MCB 101)
Default value: Size related
Change during operation: True
This parameter is active when option module VLT® General Purpose I/O MCB 101 is mounted in the drive. The options for this pa-
rameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
Table 359: Parameter 5-33 Term X30/7 Digi Out (MCB 101)
5-33 Term X30/7 Digi Out (MCB 101)
Default value: Size related
Change during operation: True
This parameter is active when option module VLT® General Purpose I/O MCB 101 is mounted in the drive. The options for this pa-
rameter are the same as those listed for parameter 5-30 Terminal 27 Digital Output.
5.6.4 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
Parameter 5-40 Function Relay
Table 360: Parameter 5-40 Function Relay
Default value: Size related
Parameter type: Option, Array [9]
Change during operation: True
Select options to define the function of the relays. Relay 1 [0], relay 2 [1]. With VLT® Extended Relay Card MCB 113 installed: Relay 3
[2], Relay 4 [3], Relay 5 [4], Relay 6 [5]. With VLT® Relay Card MCB 105 installed: Relay 7 [6], relay 8 [7], Relay 9 [8].
AU275636650261en-000101 / 130R0334 | 209Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
