5.26.4 33-5* I/O Configuration
Parameter 33-50 Terminal X57/1 Digital Input
Table 1205: Parameter 33-50 Terminal X57/1 Digital Input
33-50 Terminal X57/1 Digital Input
Default value: [0] No function
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
No function
[1]
Home switch no
[2]
Home switch nc
[3]
Neg. end switch no
[4]
Neg. end switch nc
[5]
Posi. end switch no
[6]
Posi. end switch nc
[7]
Error clear no
[8]
Error clear nc
[9]
Break prog. exe no
[10]
Break prog. exe nc
[11]
Cont. prog. exe no
[12]
Cont. prog. exe nc
[13]
Start prog. exe no
[14]
Start prog. exe nc
[15]
Program select
Parameter 33-51 Terminal X57/2 Digital Input
Table 1206: Parameter 33-51 Terminal X57/2 Digital Input
33-51 Terminal X57/2 Digital Input
Default value: [0] No function
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
No function
[1]
Home switch no
[2]
Home switch nc
[3]
Neg. end switch no
[4]
Neg. end switch nc
