Danfoss VLT AutomationDrive FC 302 Programming Guide

5.26.3 33-4* Limit Handling
Parameter 33-40 Behavior atEnd Limit Switch
Table 1196: Parameter 33-40 Behavior atEnd Limit Switch
33-40 Behavior atEnd Limit Switch
Default value: [0] Call error handler
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Call error handler
[1]
Controlled stop
Parameter 33-41 Negative Software End Limit
Table 1197: Parameter 33-41 Negative Software End Limit
33-41 Negative Software End Limit
Default value: -500000
Parameter type: Range, -1073741824 - 1073741823
Setup: 2 setups
Conversion index: 0
Data type: Int32
Change during operation: True
This parameter is active only during positioning if parameter 33-42 Negative Software Limit Active is set to [1] Active. When parameter
34-50 Actual Position reaches below the negative software limit set in this parameter, a position control fault alarm is reported.
Parameter 33-42 Positive Software End Limit
Table 1198: Parameter 33-42 Positive Software End Limit
33-42 Positive Software End Limit
Default value: 500000
Parameter type: Range, -1073741824 - 1073741823
Setup: 2 setups
Conversion index: 0
Data type: Int32
Change during operation: True
This parameter is active only during positioning if parameter 33-42 Negative Software Limit Active is set to [1] Active. When parameter
34-50 Actual Position reaches below the negative software limit set in this parameter, a position control fault alarm is reported.
Parameter 33-42 Positive Software End Limit
Table 1199: Parameter 33-42 Positive Software End Limit
33-42 Positive Software End Limit
Default value: 500000
Parameter type: Range, -1073741824 - 1073741823
Setup: 2 setups
Conversion index: 0
Data type: Int32
Change during operation: True
This parameter is active only during positioning if parameter 33-42 Negative Software Limit Active is set to [1] Active. When parameter
34-50 Actual Position reaches below the negative software limit set in this parameter, a position control fault alarm is reported.
Parameter 33-43 Negative Software End Limit Active
Table 1200: Parameter 33-43 Negative Software End Limit Active
33-43 Negative Software End Limit Active
Default value: [0] Inactive
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334 | 607Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
