Table 15: Setup Link Example
Parameter 0-14 Readout: Edit Set-ups/Channel
Table 16: Parameter 0-14 Readout: Edit Set-ups/Channel
0-14 Readout: Edit Set-ups/Channel
Parameter type: Range, -2147483648–2147483647
Change during operation: False
View the setting of parameter 0-11 Edit Set-up for each of the 4 different communication channels. When the number is shown as a
hex number, as it is in the LCP, each number represents 1 channel. Numbers 1–4 represent a setup number; F means factory setting;
and A means active setup. The channels are, from right to left: LCP, FC bus, USB, HPFB1-5.
Example
The number AAAAAA21h means the following:
The drive received the setting of setup 2 via a fieldbus channel. The selection is reflected in parameter 0-11 Edit Set-up.
A user selected setup 1 via the LCP.
All other channels are using the active setup.
Parameter 0-15 Readout: Actual Set-up
Table 17: Parameter 0-15 Readout: Actual Set-up
0-15 Readout: Actual Set-up
Parameter type: Range, 0–255
Change during operation: False
Makes it possible to read out the active setup, also when [9] Multi Set-up is selected in parameter 0-10 Active Set-up.
5.1.3 0-2* LCP Display
Define the variables shown in the LCP.
For information on how to write display texts, refer to:
Parameter 0-37 Display Text 1.
Parameter 0-38 Display Text 2.
Parameter 0-39 Display Text 3.
Parameter 0-20 Display Line 1.1 Small
Table 18: Parameter 0-20 Display Line 1.1 Small
0-20 Display Line 1.1 Small
Default value: [1617] Speed RPM
Change during operation: True
Select a variable for display in line 1, left position.
