Option
Name
Description
[2]
Set-up 2
[3]
Set-up 3
[4]
Set-up 4
Example
Use multi set-up to shift from setup 1 to setup 2 while the motor is running. Program in setup 1 first, then ensure that setup 1 and
setup 2 are synchronized (or linked). Synchronization can be performed in 2 ways:
Select the following options:
[2] Set-up 2 in parameter 0-11 Edit Set-up
Set parameter 0-12 This Set-up Linked to to [1] Set-up 1.
e75bp075.12
0-12 This Set-up Linked to
0 RPM 0.00A 1(1)
Set-up Handling 0-1*
[1] Setup 1
Illustration 26: Setup 1
While still in setup 1, copy setup 1 to setup 2. Then set parameter 0-12 This Set-up Linked to to [2] Set-up 2.
e30bp076.11
0-12 This Set-up Linked to
0 RPM 0.00A 1(1)
Set-up Handling 0-1*
[2] Setup 2
Illustration 27: Setup 2
Parameter 0-13 Readout: Linked Set-ups
Table 14: Parameter 0-13 Readout: Linked Set-ups
0-13 Readout: Linked Set-ups
Default value: 0
Parameter type: Range, 0 – 255, Array [5]
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: False
View a list of all the setups linked by parameter 0-12 This Set-up Linked to. The parameter has 1 index for each parameter setup. The
value for each index shows which setups are linked to that parameter setup.
AU275636650261en-000101 / 130R033440 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
