This parameter group contains read-only information on hardware components in the power section. All parameters in this group
are arrays:
[0]: Power card 1 (the master power card in a parallel drive, or the only power card in a drive with a single inverter section).
[1]: Power card 2 (inverter connection in a parallel drive).
[2]: Power card 3 (inverter connection in a parallel drive).
[3]: Power card 4 (inverter connection in a parallel drive).
[4]: Power card 5 (rectifier connection in a parallel drive).
[5]: Power card 6 (rectifier connection in a parallel drive).
[6]: Power card 7 (rectifier connection in a parallel drive).
[7]: Power card 8 (rectifier connection in a parallel drive).
[8]: Inrush card (optional).
[9]: Fan power card 1 (optional).
[10]: Fan power card 2 (optional).
Parameter 43-00 Component Temp.
Table 1410: Parameter 43-00 Component Temp.
43-00 Component Temp.
Default value: 0 °C
Parameter type: Range, -128 - 127 °C, Array [18]
Setup: All set-ups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the temperature of a system component. The elements of the array reference local PCB temperature sensor measurements.
Parameter 16-31 System Temp. uses all elements in this array to calculate the system temperature.
Parameter 43-01 Auxiliary Temp.
Table 1411: Parameter 43-01 Auxiliary Temp.
43-01 Auxiliary Temp.
Default value: 0 °C
Parameter type: Range, -128 - 127 °C, Array [18]
Setup: All set-ups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the temperature of an auxiliary component. The elements of the array reference the temperature measurements from the
NTC temperature sensors connected to hardware components in the drive. Refer to the Operating Guide for specifications of tem-
perature sensor placement.
Parameter 43-02 Component SW ID
Table 1412: Parameter 43-02 Component SW ID
43-02 Component SW ID
Default value: 0
Parameter type: Range, 0 - 20, Array [18]
Setup: All set-ups
Conversion index: 0
Data type: VisStr[18]
Change during operation: True
Shows the software version of the installed option.
5.32.2 43-1* Power Card Status
N O T I C E
This parameter group is only available in FC 302.
This parameter group contains read-only information on the power card status. All parameters in this group are arrays:
[0]: Power card 1 (the master power card in a parallel drive, or the only power card in a drive with a single inverter section).
[1]: Power card 2 (inverter connection in a parallel drive).
AU275636650261en-000101 / 130R0334678 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
