[2]: Power card 3 (inverter connection in a parallel drive).
[3]: Power card 4 (inverter connection in a parallel drive).
[4]: Power card 5 (rectifier connection in a parallel drive).
[5]: Power card 6 (rectifier connection in a parallel drive).
[6]: Power card 7 (rectifier connection in a parallel drive).
[7]: Power card 8 (rectifier connection in a parallel drive).
Parameter 43-10 HS Temp. ph.U
Table 1413: Parameter 43-10 HS Temp. ph.U
43-10 HS Temp. ph.U
Default value: 0 °C
Parameter type: Range, -128 - 127, Array [8]
Setup: All set-ups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the heat sink temperature at the location of the phase U IGBT power module. This measurement is not available in all enclo-
sure sizes. Parameter 16-34 Heatsink Temp. uses the value in this parameter.
Parameter 43-11 HS Temp. ph.V
Table 1414: Parameter 43-11 HS Temp. ph.V
43-11 HS Temp. ph.V
Default value: 0 °C
Parameter type: Range, -128 - 127, Array [8]
Setup: All set-ups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the heat sink temperature at the location of the phase V IGBT power module. This measurement is not available in all enclo-
sure sizes. Parameter 16-34 Heatsink Temp. uses the value in this parameter.
Parameter 43-12 HS Temp. ph.W
Table 1415: Parameter 43-12 HS Temp. ph.W
43-12 HS Temp. ph.W
Default value: 0 °C
Parameter type: Range, -128 - 127, Array [8]
Setup: All set-ups
Conversion index: 100
Data type: Int8
Change during operation: True
Shows the heat sink temperature at the location of the phase W IGBT power module. This measurement is not available in all enclo-
sure sizes. Parameter 16-34 Heatsink Temp. uses the value in this parameter.
Parameter 43-13 PC Fan A Speed
Table 1416: Parameter 43-13 PC Fan A Speed
43-13 PC Fan A Speed
Default value: 0 RPM
Parameter type: Range, 0 - 65535, Array [8]
Setup: All set-ups
Conversion index: 67
Data type: Uint16
Change during operation: True
Shows the measured speed of fan A on the power card. Each power card has up to 3 fan connections. Place the fan in the drive
according to the Operating Guide. A typical placement for fan A is in the backchannel (the external fan). The value of this parameter
is:
The actual fan speed when there is a DC fan in the drive.
Relative speed when there is an AC fan in the drive.
AU275636650261en-000101 / 130R0334 | 679Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
