Danfoss VLT AutomationDrive FC 302 Programming Guide

Parameter 6-21 Terminal 54 High Voltage
Table 408: Parameter 6-21 Terminal 54 High Voltage
6-21 Terminal 54 High Voltage
Default value: 10 V
Parameter type: Range, par. 6-20 V - 10 V
Setup: All setups
Conversion index: -2
Data type: Int16
Change during operation: True
Enter the high voltage value. This analog input scaling value should correspond to the high reference feedback value set in parame-
ter 6-25 Terminal 54 High Ref./Feedb. Value.
Parameter 6-22 Terminal 54 Low Current
Table 409: Parameter 6-22 Terminal 54 Low Current
6-22 Terminal 54 Low Current
Default value: Size related
Parameter type: Range, par. 0 - par. 6-23 mA
Setup: All setups
Conversion index: -5
Data type: Int16
Change during operation: True
Enter the low current value. This reference signal should correspond to the minimum reference value, set in parameter 3-02 Mini-
mum Reference. Enter the value that exceeds 2 mA to activate the live zero timeout function in parameter 6-01 Live Zero Timeout
Function.
Parameter 6-23 Terminal 54 High Current
Table 410: Parameter 6-23 Terminal 54 High Current
6-23 Terminal 54 High Current
Default value: 20 mA
Parameter type: Range, par. par. 6-22 mA - 20 mA
Setup: All setups
Conversion index: -5
Data type: Int16
Change during operation: True
Enter the high current value corresponding to the high reference feedback value set in parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
Parameter 6-24 Terminal 54 Low Ref./Feedb. Value
Table 411: Parameter 6-24 Terminal 54 Low Ref./Feedb. Value
6-24 Terminal 54 Low Ref./Feedb. Value
Default value: Size related
Parameter type: Range, -999999.999 - 999999.999 ReferenceFeed-
backUnit
Setup: All setup
Conversion index: -3
Data type: Int32
Change during operation: True
Enter the analog input scaling value that corresponds to the minimum reference feedback value set in parameter 3-02 Minimum
Reference.
Parameter 6-25 Terminal 54 High Ref./Feedb. Value
Table 412: Parameter 6-25 Terminal 54 High Ref./Feedb. Value
6-25 Terminal 54 High Ref./Feedb. Value
Default value: Size related
Parameter type: Range, -999999.999 - 999999.999 ReferenceFeed-
backUnit
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: True
Enter the analog input scaling value that corresponds to the maximum reference feedback value set in parameter 3-03 Maximum
Reference.
AU275636650261en-000101 / 130R0334 | 235Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
