Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[0]
Digital input
A digital input triggers the coasting function.
[1]
Bus
A serial communication port or the fieldbus triggers the coasting function.
[2]
Logic AND
The fieldbus/serial communication port and a digital input trigger the coasting function.
[3]*
Logic OR
The fieldbus/serial communication port or a digital input triggers the coasting function.
Parameter 8-51 Quick Stop Select
Table 528: Parameter 8-51 Quick Stop Select
8-51 Quick Stop Select
Default value: [3] Logic OR
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the trigger for the quick stop function.
Option
Name
Description
[0]
Digital input
A digital input triggers the quick stop function.
[1]
Bus
A serial communication port or the fieldbus triggers the quick stop function.
[2]
Logic AND
The fieldbus/serial communication port and a digital input trigger the quick stop function.
[3]*
Logic OR
The fieldbus/serial communication port or a digital input triggers the quick stop function.
Parameter 8-52 DC Brake Select
Table 529: Parameter 8-52 DC Brake Select
8-52 DC Brake Select
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select control of the DC brake via the terminals (digital input) and/or via the fieldbus.
N O T I C E
When parameter 1-10 Motor Construction is set to [1] PM non-salient SPM, only selection [0] Digital input is available.
Option
Name
Description
[0]
Digital input
Activate a start command via a digital input.
[1]
Bus
Activate a start command via a serial communication port or fieldbus option.
[2]
Logic AND
Activate a start command via the fieldbus/serial communication port and also via 1 of the digital inputs.
[3]
Logic OR
Activate a start command via the fieldbus/serial communication port or via 1 of the digital inputs.
AU275636650261en-000101 / 130R0334 | 299Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
