In Ethernet/IP: If no CIP connection is present, None is shown.
In EtherCAT: If no connection is active, None is shown, otherwise it shows the active PDO.
In POWERLINK: If no connection is active, None is shown, otherwise it shows the active PDO (23).
Parameter 12-21 Process Data Config Write
Table 621: Parameter 12-21 Process Data Config Write
12-21 Process Data Config Write
Default value: Size related
Parameter type: Option, Array [81]
Setup: All setups
Conversion index: –
Data type: Uint16
Change during operation: True
Option
Name
Description
[-]
None
[109]
Mode of operation
[302]
Minimum reference
[303]
Maximum reference
[312]
Catch up/slow down value
[321]
Touch target
[322]
Master scale numerator
[323]
Master scale denominator
[326]
Master Offset
[328]
Master offset speed ref
[341]
Ramp 1 ramp up time
[342]
Ramp 1 ramp down time
[351]
Ramp 2 ramp up time
[352]
Ramp 2 ramp down time
[361]
Ramp 3 ramp up time
[362]
Ramp 3 ramp down time
[380]
Jog/homing ramp time jog ramp time
[381]
Quick stop ramp time
[411]
Motor speed low limit [RPM]
[412]
Motor speed low limit [Hz]
[413]
Motor speed high limit [RPM]
[414]
Motor speed high limit [Hz]
[416]
Torque limit motor mode
[417]
Torque limit generator mode
[482]
Power limit motor mode
AU275636650261en-000101 / 130R0334352 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
