Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[0]
False
Select the boolean (true or false) input to activate smart logic control. Enters the fixed value
False.
[1]
True
Enters the fixed value True.
[2]
Running
The motor runs.
[3]
In range
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warn-
ing Current Low to parameter 4-53 Warning Speed High.
[4]
On reference
The motor runs on reference.
[5]
Torque limit
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit
Generator Mode is exceeded.
[6]
Current limit
The motor current limit set in parameter 4-18 Current Limit is exceeded.
[7]
Out of current range
The motor current is outside the range set in parameter 4-18 Current Limit.
[8]
Below I
low
The motor current is lower than set in parameter 4-50 Warning Current Low.
[9]
Above I
high
The motor current is higher than set in parameter 4-51 Warning Current High.
[10]
Out of speed range
The speed is outside the range set in parameter 4-52 Warning Speed Low and parameter 4-53
Warning Speed High.
[11]
Below speed low
The output speed is lower than the setting in parameter 4-52 Warning Speed Low.
[12]
Above speed high
The output speed is higher than the setting in parameter 4-53 Warning Speed High.
[13]
Out of feedb. range
The feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
[14]
Below feedb. low
The feedback is below the limit set in parameter 4-56 Warning Feedback Low.
[15]
Above feedb. high
The feedback is above the limit set in parameter 4-57 Warning Feedback High.
[16]
Thermal warning
The thermal warning turns on when the temperature exceeds the limit in the motor, the drive,
the brake resistor, or the thermistor.
[17]
Mains out of range
The mains voltage is outside the specified voltage range.
[18]
Reversing
The output is high when the drive is running counterclockwise (the logical product of the status
bits running AND reverse).
[19]
Warning
A warning is active.
[20]
Alarm (trip)
A (trip) alarm is active.
[21]
Alarm (trip lock)
A (trip lock) alarm is active.
[22]
Comparator 0
Use the result of comparator 0.
[23]
Comparator 1
Use the result of comparator 1.
[24]
Comparator 2
Use the result of comparator 2.
[25]
Comparator 3
Use the result of comparator 3.
[26]
Logic rule 0
Use the result of logic rule 0.
[27]
Logic rule 1
Use the result of logic rule 1.
AU275636650261en-000101 / 130R0334374 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
