Danfoss VLT AutomationDrive FC 302 Programming Guide

Option
Name
Description
[0]*
Clockwise
[1]
Counter clockwise
Parameter 17-61 Feedback Signal Monitoring
Table 937: Parameter 17-61 Feedback Signal Monitoring
17-61 Feedback Signal Monitoring
Default value: [1] Warning
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: False
Select which action the drive should take if a faulty encoder signal is detected. The encoder function in parameter 17-61 Feedback
Signal Monitoring is an electrical check of the hardware circuit in the encoder system.
Option
Name
Description
[0]
Disabled
[1]*
Warning
[2]
Trip
[3]
Jog
[4]
Freeze output
[5]
Max speed
[6]
Switch to open loop
[7]
Select setup 1
[8]
Select setup 2
[9]
Select setup 3
[10]
Select setup 4
[11]
Stop & trip
[12]
Trip/warning
[13]
Trip/catch
Parameter 17-67 Raw Inc. Quad Counter
Table 938: Parameter 17-67 Raw Inc. Quad Counter
17-67 Raw Inc. Quad Counter
Default value: 0
Parameter type: Range, 0 - 65535
Setup: All setups
Conversion index: 0
Data type: Uint16
Change during operation: False
N O T I C E
This parameter is only available with software version 48.9X.
Shows the raw incremental counter value in quad counts (4 times pulse count) of an encoder connected to VLT® Encoder Input MCB
102. It can be an incremental encoder or the incremental part of a dual-channel absolute encoder. MCB 102 must be selected as
AU275636650261en-000101 / 130R0334524 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
