Danfoss VLT AutomationDrive FC 302 Programming Guide

•
•
•
•
•
•
•
•
•
•
Parameter 0-33 Source for User-defined Readout
Table 24: Parameter 0-33 Source of User-defined Readout
0-33 Source of User-defined Readout
Default value: [240] Default Source
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Enter the source of the user-defined readout.
Option
Name
Description
[105]
Torque related to rated
[143]
PID Clamped Output 4–20mA
[240]*
Default Source
Parameter 0-37 Display Text 1
Table 25: Parameter 0-37 Display Text 1
0-37 Display Text 1
Default value: 0
Parameter type: Range, 0–25
Setup: 1 setup
Conversion index: 0
Data type: VisStr[25]
Change during operation: True
Enter a text which can be viewed in the graphical display by selecting [37] Display Text 1 in
Parameter 0-20 Display Line 1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Parameter 0-38 Display Text 2
Table 26: Parameter 0-38 Display Text 2
0-38 Display Text 2
Default value: 0
Parameter type: Range, 0–25
Setup: 1 setup
Conversion index: 0
Data type: VisStr[25]
Change during operation: True
Enter a text which can be viewed in the graphical display by selecting [38] Display Text 2 in
Parameter 0-20 Display Line 1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Parameter 0-39 Display Text 3
Table 27: Parameter 0-39 Display Text 3
0-39 Display Text 3
Default value: 0
Parameter type: Range, 0–25
Setup: 1 setup
Conversion index: 0
Data type: VisStr[25]
Change during operation: True
AU275636650261en-000101 / 130R0334 | 53Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
