Bit
0
1
13
Set-up select LSB
–
14
Set-up select MSB
–
15
No reversing
Reversing
1
Different from [0] FC Profile. Options for bits 0–2, and 12–15 in parameter 8-14 Configurable Control Word CTW:
[11] Start Homing
[12] Activate Touch Probe
[13] Sync. to Pos. Mode
[14] Ramp 2
[15] Relay 1
[16] Relay 2
[17] Speed Mode
[18] Start Virtual Master
[19] Activate Master Offset
[21] Target Inverse
[26] Home Sensor
[27] Touch Sensor
[28] Position Vir. Master
[29] Set Master Home
[30] Set Vir. Mas. Pos. to Actual
[31] Activate CAM Table
Table 1433: Status Word
Bit
0
1
0
Control not ready
Control ready
1
Drive not ready
Drive ready
2
Coasting
Enable
3
No error
Trip
4
(1)
Not homed
Home done
5
Reserved
Reserved
6
No error
Trip lock
7
No warning
Warning
8
(1)
Not on target position
Target position reached
9
Local operation
Bus control
10
Out of frequency limit
Frequency limit OK
11
No operation
In operation
12
Drive OK
Stopped, auto start
AU275636650261en-000101 / 130R0334 | 689Danfoss A/S © 2022.12
Integrated Motion Controller
VLT AutomationDrive FC 301/302
Programming Guide

Danfoss VLT AutomationDrive FC 302 Specifications

General

Category	DC Drives
Control Method	Flux Vector Control
Communication Options	CANopen, PROFIBUS
Cooling	Forced convection
Enclosure	IP20, IP21, IP55, IP66
Protection Class/Rating	IP20
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit
Approvals	CE, UL, cUL
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Output Voltage	0 V to Input Voltage
