Page 36
SNMP support
The SP Series Card Printer with Built-in Ethernet supports the following SNMP (simple network management
protocol) features:
• The printer has an SNMP agent which supports the printer MIB (management information block) and MIB-II.
The agent supports SNMPv1 and SNMPv2c.
• If you connect the printer to the network using a print server, the print server can provide SNMP data about
itself (if supported). You cannot obtain SNMP data about the printer through a print server. SNMP data about
the printer is only available through the printer Ethernet port; if you require SNMP data about the printer and
use a print server to send data, you must also connect the printer Ethernet port to the network to provide the
SNMP data.
• The MIB-II is described in RFC (request for comment) 1213 and includes RFC 2233, the Interfaces Group
MIB using SMI v2.
• The printer MIB is described in RFC 1759 (which requires inclusion of part of the Host Resources MIB, RFC
1514).
• For more information about SNMP standards, see the RFC pages of the Internet Engineering Task Force
Web site at
http://www.ietf.org/rfc.html.
