Datalogic DS8100A User Manual

xi
Figure C – Display and Keypad Panel
Programming Keypad
Power On LED (Green)
Phase On LED (Yellow)
Encoder LED (Yellow)
1
2
3
4
TX Data LED (Green)
Network LED (Red)
LCD Display
5
6
7
Figure D – Connector Panel for Standard Models
Lonworks 17-pin male connector
Lonworks 17-pin female connector
1
2
Serial interface and I/O 26-pin connector
3
Figure E – Connector Panel for Ethernet Models
Figure F – Connector Panel for (older) Ethernet Models
Lonworks 17-pin male connector
Lonworks 17-pin female connector
Harting RJ industrial connector
1
2
4
Serial interface and I/O 26-pin connector
3
1
2
3
1
2
4
3
7
1
2
3
4
5
6
1
2
4
3
Lonworks 17-pin male connector
Lonworks 17-pin female connector
Ethernet M12 4-pin female connector
1
2
4
Serial interface and I/O 26-pin connector
3
