DS8100A REFERENCE MANUAL
16
2
192.3
[7.57]
275.1
[10.83]
254
[10.00]
28°
45°
67.5
[2.66]
50
[1.97]
46.7
[1.84]
50
[1.97]
45°
mm
inch
67.5
[2.66]
46.8
[1.84]
Figure 8 - DS8100A Oscillating Mirror Model Overall Dimensions
2.2.2 Mounting the Scanner with Accessories
The following accessories allow installing the DS8100A reader in the most suitable position
for your network layout:
- ST-163 mounting bracket;
- FBK-8100 fast bracket.
The ST-163 is a 90° mounting bracket to be mounted on the reader as displayed in the
image below:
Figure 9 – Mounting the ST-163 Mounting Bracket
