DS8100A REFERENCE MANUAL
112
12
12 TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage
20 to 30 Vdc
Power Consumption
20 W typical
1.3 - 0.9 A max. (including startup current)
Common Communication
Interfaces
Main
Baud Rate
RS232
1200 to 115200
RS485 full-duplex
RS485 half-duplex
Auxiliary
RS232
1200 to 115200
Other
Lonworks
1.25 Mb/s
Model–Dependent Communication
Interfaces
Ethernet
100 Mb/s
Inputs
Ext. Trigger 1, Encoder
2 aux. digital inputs
(optocoupled NPN or PNP)
Outputs
3 software programmable digital
Outputs
(optocoupled)
OPTICAL FEATURES
Light Receiver
Avalanche photodiode
Wavelength
630 to 680 nm
Safety Class
Class 2 - EN60825-1; Class II - CDRH
Light Source
Up to 4 semiconductor laser diodes
Laser Control
Security system to turn laser off in case of motor slow
down
READING FEATURES
Scan Rate
1000 scans/s
Maximum Resolution
(see reading diagrams in par. 9.4)
Max. Reading Distance
Max. Reading Width
Max. Depth of Field
Aperture Angle
USER INTERFACE
LCD Display
2 lines by 20 characters LCD
Keypad
3 keys
LED Indicators
Power On (green)
Phase On (yellow)
Encoder (yellow)
TX Data (green)
Network (red)
