DS8100A REFERENCE MANUAL
100
9
DS8100A-3X10 (0.38 mm/15 mils)
The diagram shows an average reading area obtained considering different barcode types of
variable quality.
0
24
16
40
(in)
32
48
0
40
60
80
(cm)
100
120
140
160
56
64
(in)
30
20
0
10
(cm)
50
60
70
40
-30
-20
-10
-50
-60
-70
-40
12
8
0
4
20
24
28
16
-12
-8
-4
-20
-24
-28
-16
Note: (0,0) is the center of the laser beam output window.
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
"Pitch" angle = 0°
"Skew" angle = 10°
"Tilt" angle = 0°
Reading mode = Linear
