Datalogic DS8100A User Manual

ALTERNATIVE LAYOUTS
115
A
Ethernet Models
In this example no External Trigger is used and the CBX100 only supplies the reader. The
DS8100A (Ethernet model) is connected to a remote Host. It can be activated by a signal
generated by the remote Host or always be active if working in Automatic operating mode.
Figure 104 – Point-to-Point for Ethernet Models
Terminal
DS8100A
1
 Auxiliary Serial Interface (Data Tx to Terminal Local
Echo) (RS232)
Remote
Host
PWR-120
CBX
CAB-F0x
Ethernet
Network
