The table below gives the pinout of the CBX100/500 terminal block connectors. Use this
pinout when the DS8100A reader is connected by means of the CBX100/500:
CBX100/500 Terminal Block Connectors
Power Supply Input Voltage +
Power Supply Input Voltage -
External Trigger
(PS) Input
Power Source – External Trigger
External Trigger A (polarity insensitive) for PS
External Trigger B (polarity insensitive) for PS
Power Reference – External Trigger
Input 2A (polarity insensitive) for Encoder
Input 2B (polarity insensitive) for Encoder
Power Reference – Outputs
Output 3A (polarity insensitive)
Output 3B (polarity insensitive)
Input 3A (polarity insensitive)
Input 4A (polarity insensitive)
Power Reference – Other I/O
Input 3B and 4B (common) (polarity insensitive)
Input 3B and 4B (common) (polarity insensitive)
Auxiliary Interface Reference
* Do not leave floating, see par. 3.2.2 for connection details.
Do not connect GND and SGND to different (external) ground references.
GND and SGND are internally connected through filtering circuitry which
can be permanently damaged if subjected to voltage drops over 0.8 Vdc.
DS8100A scanners do not support Host Interface Modules with the
CBX500. Use the CBX800 Gateway for Host Interface Applications,
(Fieldbus and non Fieldbus).
