Setting Up the Reader
2 GRYPHON™ I GBT/GM4500
DataBar Expanded Stacked, GS1 DataBar Stacked, GS1
DataBar, Stacked Omnidirectional). The data stream -
acquired from decoding a symbol - is rapidly sent to the host.
The reader is immediately available to read another symbol.
SETTING UP THE READER
Follow the steps below to connect and get your reader up
and communicating with its host.
1. Configure the Base Station starting on this page.
2. Charge the Batteries (see page 11).
3. Link to the Base Station (see page 16).
4. Select the Interface Type (see page 18).
5. Configure the Reader starting on page 19 (optional,
depends on settings needed)
NOTE: According to recent modification of Regula-
tion for shipping Li-Ion based battery packs, the
products and their spare battery packs parts are
shipped with a very low residual charge (low state
of charge).
Hence the needs:
• that a new product must be fully recharged
before starting to use it.
and
• that battery packs of the stocked products
GBT/GM4500 and spare battery pack parts
must be periodically recharged. For instance,
by using a WLC4090 cradle powered up with
a 12V Datalogic AC/DC adapter (cod.8-0935)
for at least 30 minutes each 3 months.

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
