Datalogic Gryphon GBT4500 Series

Reader, Cradle and LEDs Description
6 GRYPHON™ I GBT/GM4500
READER, CRADLE
AND LEDS DESCRIPTION
LEDs on the gun provide information about the battery
charging status as well as data transmission.
Figure 4 - Gryphon Base LEDs
1. Scan Window 2. Trigger
3. Battery & Recharge LED 4. Good Read LED
5. USB Port
1. Service Button 2. Power LED
3. Recharge LEDs 4. Cable Release Hole
5. Communication Port 6. Aux Power Port
1
2
3
4
5
5
6
1
2
3
4
