Datalogic Gryphon GBT4500 Series User Manual

LED and Beeper Indications
QUICK REFERENCE GUIDE 37
LED AND BEEPER INDICATIONS
The imager’s beeper sounds and its illumination flashes or
changes color to indicate various functions or errors on
the reader. A “Green Spot” also lights to indicate a good
read. The tables below list these indications. Reference
the PRG for a more detailed list.
REGULATORY
See Regulatory Addendum
RADIO CHARACTERISTICS
Wireless Technology Star™ 910 MHz Star™ 433 MHz Bluetooth
Range (in open air) 50 m 50 m 100 m
Max number of
devices per base sta-
tion
16 7
INDICATION LED BEEPER
Power-up
Upper LED flashes/blinks
on power-up, however,
this may be too rapid to
view. With a USB inter-
face, the LED blinks until
enumeration with the host
is completed.
Imager beeps four times
at highest frequency and
volume upon power-up.
Good Read
Upper green LED comes
on for programmed time
(default).
LED behavior for this indi-
cation is configurable
using Aladdin utility.
One beep at current fre-
quency, volume, mono/
bi-tonal setting upon a
successful label scan. It is
also possible to upload
custom jingles with Alad-
din.
ROM Failure 200ms on / 200ms off
Imager sounds one error
beep at highest volume
for 200 mS.
Limited Scanning
Label Read
N/A
Imager 'chirps' six times
at the highest frequency
and current volume.
Imager Disabled
The LED blinks continu-
ously 100mS on / 900 mS
off
N/A

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
