Datalogic Gryphon GBT4500 Series User Manual

Setting Up the Reader
QUICK REFERENCE GUIDE 3
Positioning the Base Station
The base station/charger may be set up in desk applica-
tion to hold the reader in two different positions, either a
horizontal or vertical position, in order to provide the
most comfortable use depending on the needs.
Figure 1 - Horizontal Position
This position is preferred, unless a different specific posi-
tioning is required, for its outmost ease of insertion as
well as the minimum effort and attention required to cus-
tomer when docking the scanner.
Figure 2 - Presentation Position
This position is preferred if the scanner is to be used in
stand mode and not needed to be often removed from
base station.

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
