Datalogic Gryphon GBT4500 Series

System and Network Layouts
10 GRYPHON™ I GBT/GM4500
SYSTEM AND NETWORK LAYOUTS
Stand Alone Layouts
Figure 9 - Single Reader Layout
Figure 10 - Multiple Reader Layout
In stand alone systems, each cradle is connected to a sin-
gle Host.
HOST
GRYPHON™ I
CRADLE
HOST
GRYPHON™ I
CRADLE
