Datalogic Gryphon GBT4500 Series User Manual

Configuring the Interface
QUICK REFERENCE GUIDE 21
Keyboard Interface
Use the programming bar codes to select options for USB-
Keyboard and Wedge Interfaces.
KEYBOARD
Select KBD-AT
(AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/standard key encoding)
Select KBD-AT-NK
(IBM AT PS2 with standard key encoding
but without external keyboard.)
Select KBD-AT-ALT
(AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Alternate Key)
Select KBD-AT-ALT-NK
(Keyboard Wedge for IBM AT PS2 with alternate key encoding
but without external keyboard)

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
