Technical Specifications
34
GRYPHON™ I GBT/GM4500
TECHNICAL SPECIFICATIONS
The following table contains Physical and Performance
Characteristics, User Environment and Regulatory infor-
mation.
PHYSICAL CHARACTERISTICS
Color
Black
White
Dimensions
Gun only (LHD):
68.4 x 165.8 x 110.0mm (2.7" x 6.5" x 4.3")
Cradle only (LHD):
94.6 x 128.7 x 212.7mm (3.7" x 5.1" x 8.4")
Gun on Cradle Horizontal mount (LHD):
94.6 x 134.0 x 212.7mm (3.7" x 5.3" x 8.4")
Gun on Cradle Presentation mount (LHD):
94.6 x 170.7 x 183.6mm (3.7" x 6.7" x 7.2")
Weight
Approx. 235 g (8.29 oz.) GBT4500 or GM4500 and bat-
tery pack included
Battery Pack is approx. 65 g (2.29 oz.)
ELECTRICAL CHARACTERISTICS
Power Supply
(WLC4190)
5V to 14V +/-5% in the Communication Port
5V to 14V +/-5% in the Aux Power Port
NOTE: Aux Power Port is recommended when long
cables are connected to Communication Port
Consumption
(Typical)
Gun Only: 330 mA @ 3,7V(Operative)
Cradle Only: 80 mA @ 5V (Operative)
Cradle with Gun in Charge (Scan while Charging):
475 mA (PC host USB)
1150 mA (5V on Aux Power Port)
520 mA (12V on Aux Power Port)
Gun Charging via micro USB:
480 mA (PC host port, no Scan)
900 mA (wall adapter, no Scan)
1160 mA (wall adapter, Scan while Charging)
Battery Capacity Li-Ion 3.6V, 3250 mAh (11.7W/h)
Recharge Time
(Typical)
Values valid for a fully depleted battery USB Only:
11h (no Scan)
15h (Scan while Charging)
Using Aux Power Port:
3h (no Scan)
3.5h (Scan while Charging)
Using micro USB (wall adapter):
2h (no Scan, with Wall Adapter)
4.6h (no Scan, with PC Host)
Max. Scan Rate 50 frames/sec
Reading Indicators
Top and rear illumination, Good Read Spot, Beep,
Vibrator
