Datalogic Gryphon GBT4500 Series User Manual

Technical Specifications
QUICK REFERENCE GUIDE 35
ENVIRONMENTAL CHARACTERISTICS
Operating Tempera-
ture
0 °C to + 50 °C (+32° F to +122 °F)
Storage Temperature -40 °C to + 70 °C (-40 ° F to +158 °F)
Humidity 95% non condensing
Drop Resistance
IEC 68-2-32 Tested
1.8 m (6 ft)
ESD Protection 16 KV
Protection Class IP52
Cable Length Refer to www.datalogic.com
OPTICAL CHARACTERISTICS
Optical Format 1/4"
Active Imager Size 3896 um (H) x 2453 um (V)
Active Pixels 1280 H x 800 V
Illumination System
LED source
Warm White Emission
(wavelength = 350 - 770 nm)
Hyper Red Emission (wavelength = 660 nm, DGM
model only)
IEC 62471 Exempt Risk Group
Aiming System
RED laser source
IEC 60825-1 Class 2
Radiation 1 mW Avg., Emitted wavelength 650
nm, 10ms pulse
Ambient Light Up to 100,000 lux
Tilt Tolerance
a
a. Based on ISO 15423 specifications.
0° - 360°
Pitch Tolerance
a
± 65°
Skew Tolerance
a
± 65°
Field of View
a
36° H x 23° V
PCS
(Datalogic Test Chart)
minimum 15%

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
