Datalogic Gryphon GBT4500 Series User Manual

Configuring the Interface
22 GRYPHON™ I GBT/GM4500
★ = default value
Scancode Tables
Refer to Gryphon I GD/GBT/GM4500 PRG for information
about control character emulation for keyboard inter-
faces.
Country Mode
This feature specifies the country/language supported by
the keyboard. Only the following interfaces support ALL
Country Modes.
• USB Keyboard with alternate key encoding
• USB Keyboard with standard key encoding
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Std Key Encoding
• Keyboard Wedge for IBM AT PS2 with standard key
encoding but without external keyboard
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
without Alternate Key
• Keyboard Wedge for IBM AT PS2 without alternate
key encoding but without external keyboard
All other interfaces support ONLY the following Country
Modes: U.S., Belgium, United Kingdom, France, Germany,
Italy, Spain, Sweden.
KEYBOARD (CONTINUED)
★ Select USB Keyboard
(USB Keyboard with standard key encoding)
Select USB Alternate Keyboard
(USB Keyboard with alternate key encoding)

Datalogic Gryphon GBT4500 Series Specifications

General

Drop Resistance	1.8 m / 5.9 ft
Sealing	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Light Source	LED
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Ambient Light	0 - 100, 000 lux
Drop Specification	Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
IP Rating	IP52
Connectivity	Bluetooth
Battery Type	Lithium-Ion
Decode Capability	1D / 2D, Postal Codes, Stacked Codes
Radio Range (Open Air)	Up to 100 m / 328 ft
Interfaces Supported	USB, RS-232, Keyboard Wedge
Type	Handheld
Technology	2D imager
Scan Rate	60 frames/sec
Supported Barcodes	1D, 2D, Postal
Humidity	5 - 95% (Non-condensing)
Power Supply	5 VDC
Battery	Rechargeable Battery Pack
Weight	245.0 g / 8.6 oz
