Replacing the Battery Pack
QUICK REFERENCE GUIDE
45
2. Extract the battery pack from its slot.
3. Insert the new battery in the same position.
4. Replace the battery holder cap, plug in the connector
and return the contacts circuit to its previous loca-
tion.
5. Insert the cover in the handle and screw it into place.
NOTE: When inserting the new battery into the
handle, take care to position the battery and the
connector as described above.
