ENTER/EXIT PROGRAMMING MODE DISPLAY AND KEYBOARD FEATURES
266
POWERSCAN™ PD/PM/PBT9600
Quantity/Code Send Mode
This feature defines the rules that will be used to send a QTY/CODE pair:
0. Code is transmitted with QTY field (and its predefined format) preceding CODE
field (and its predefined format)
1. Code is transmitted with CODE field (and its predefined format) preceding QTY
field (and its predefined format)
2. Code in CODE field is sent out for the number of times defined in the QTY field
Quantity/Code Separator
This feature allows the insertion of a separator between Qty/Code pairs.
Qty precedes Code
$CPWEH00
$CPWEH01
Code precedes Qty
Code transmitted Qty times
$CPWEH02
$CPWQP00
No separator
Set Qty/Code string separator
$CPWQP
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the barcode
at left. Next scan 1 digit from Appendix G, Keypad (in
the range 1-8) representing the number of charac-
ters to be used as separator.
Finally, define the separator string by reading the
desired characters from the ASCII table at the back
of this manual, expressed in hexadecimal form. End
by scanning the ENTER/EXIT bar code again.
To Next Page
