PD9600 TECHNICAL SPECIFICATIONS
PRODUCT REFERENCE GUIDE 347
ENVIRONMENTAL CHARACTERISTICS
Operating Temperature -20° to 50° C (-4° to 122° F)
Storage Temperature -40° to 70° C (-40° to 158° F)
Humidity 0 to 95% non-condensing
Drop Resistance
Withstands 50 drops from 2.5 m/8.2 ft @20° C;
Withstands 50 drops from 2.0 m/6.6 ft @-20° C
Ambient Light Immunity 100,000 Lux
Contaminants: Spray/rain,
Dust/particulates
IP67 and IP65
ESD Protection 20 KV
Regulatory See Regulatory Addendum
DOF - DEPTH OF FIELD (TYPICAL)
A
Symbology DOF range
Code 128
PD96XX-SR:
5 mils: 6.4-30.9 cm (2.5-12.2 in)
20 mils: 4-103.7 cm (1.6-40.8 in)
40 mils: 5.5-175 cm (2.2-68.9 in)
PD96XX-DC:
5 mils: 3.1-39.7 cm (1.2-15.6 in)
20 mils: 3.5-119.1 cm (1.3-46.9 in)
40 mils: 4.5-186.6 cm (1.7-73.4 in)
PD96XX-HP:
2.5 mils: 6.3-11.5 cm (2.5-4.5 in)
5 mils: 3.8-41 cm (1.5-16.1 in)
20 mils: 4-157 cm (1.6-61.8 in)
40 mils: 5.5-242.9 cm (2.1-95.6 in)
EAN13
PD96XX-SR:
13 mils: 4-67.5 cm (1.5-26.5 in)
PD96XX-DC:
13 mils: 3.5-102 cm (1.3-40.1 in)
PD96XX-HP:
13 mil: 4-120.2 cm (1.5-40.2 in)
PDF417
PD96XX-HP:
10 mils:0.5-46.1 cm (0.2-18.1 in)
Datamatrix
PD96XX-SR:
10 mils: 6.4-30 cm (2.5-11.8 in)
PD96XX-DC:
10 mils: 4.2-30.2 cm (1.6-11.8 in)
PD96XX-HP:
4 mils: 6.5-9.3 cm (2.5-3.6 in)
10 mils: 4.2-32.1 cm (1.6-12.6 in)
Max Resolution
PD96XX-SR:
1D = 3 mils, 2D = 6 mils
PD96XX-DC:
1D = 3 mils, 2D = 5 mils
PD96XX-HP:
1D = 2.5 mils, 2D = 4 mils
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environ-
mental light, 20°C, label inclination 10°
